Charge your Type 2 electric vehicle from a domestic 3-pin socket. The charging cable in-line power controller offers built-in safety protection covering short circuit, temperature, earth fault, and overload protection.  Safe and convenient Mode 2 portable charging solutions from Sync Energy.

  • 5m length
  • Provides safe and intelligent portable EV charging for all plug-in electric vehicles*
  • Perfect for travelling to destinations that only offer a domestic (13A UK 3 pin) socket
  • UK 3 pin plug to Type 2 EV plug
  • Charges up-to 10A, 2.4kW - up-to 8 miles per charging hour
  • 5 metres of high performance cable
  • IP65 rated (Control box) - IP65 when connected to vehicle, IP55 when not in use and end-cap applied
  • LED charging status indicator
  • Optional carry case available (Code : EVCASE-01)
  • Also available as 10m length

*Any portable charger used for regular charging should be connected via a dedicated circuit including a socket designed and marked "Suitable for EV charging"


Charge modes explained

Charging an electric car can be done at home, a place of work, or by using 'destination' chargers enroute. Each option typically gives different charge times and costs.

These options are termed 'charging modes' and are split in to 4 categories indicating the type of charger being used and its power output:

Home charging: Workplace charging:
Mode 2 (AC single-phase supply)
2.3kW max from a domestic 3-pin socket using a cable with an inbuilt protection device and power control that emulates basic Mode 3 charger signals.
Typical charge times for a 60kW battery = 26 hours+
Mode 3 (AC three-phase supply)
Up-to 22kW - Limited to three-phase power supplies only (charging at work, or commercial premises. Very few homes are specified with 3 Phase power, tethered or socketed connections with smart control and protection.
Typical charge times for a 60kW battery = 3 hours approx
Mode 3 (AC single phase supply)
7.4kW - a typical dedicated home charging point (like those available from Sync Energy), tethered or untethered with smart control and protection.
Typical charge times for a 60kW battery = 8 hours approx
Destination charging:
Mode 4 (DC current)
22kW-250kW+ - Typically rapid and super-rapid destination chargers, found at motorway services, supermarkets, shopping malls.
Typical charge times for a 60kW battery = < 60 minutes for super-rapid chargers

Which cable do I need to purchase – Mode 2 or Mode 3?

Mode 2 Mode 3
  • Offers EV charging from a standard domestic 3-pin UK socket
    • Max charge 2.3kW
  • Mode 2 cables are slow at charging electric vehicles and do not offer the same safety or Smart capabilities as Mode 3 chargers
  • Ideal as a backup charger when visiting friends and relatives, and if you don’t have a Mode 3 charger at home
  • Often referred to as Granny Chargers/Cables
  • 13A plug-to-Type 2 connection into an electric vehicle
  • Sync Energy advise to ideally connect via a 13A socket designed and marked ‘Suitable for EV charging’
  • Mode 3 cables are required to use a Socketed Mode 3 wall charger (“tethered” chargers have their own inbuilt cable)
  • Max charge 7.4kW (single phase AC – found in most UK homes)
  • Max charge 22kW (3 Phase AC – found in workplace chargers or at high-end bespoke build UK homes when specified)
  • No charging capability by themselves, they must be connected to an EV charger
  • Has Type 2 plugs to connect to an EV and EV charger

Cable care and charging safety

  • The cable, control box and Type 2 connector should be kept out of puddles (these have IP65 rating when connected to the car), and the 13A 3-pin plug should never be used outside other than within an IP rated weatheproof socket enclosure.
  • Please remember to use the rubber dust cap to keep debris from collecting in the Type 2 connector when not in use.
  • Any portable charger used for regular charging should be connected via a dedicated circuit including a socket designed and marked "Suitable for EV charging"
  • Moisture is the most common issue experienced and will lead to corrosion of the pins which are not covered by our warranty.

What are the risks of charging in the rain?

Care should be taken to not allow water to enter the car charging socket or charging cable plug. Water can get in to the plug and charging socket during the insertion and removal of the plug from the car. As soon as the charge port is opened, or unplugging your car from a charger, rain can get on to the pins and stay there until the next time you charge.

Please note: This EV cable is NOT an extension cable.


Delivery

We offer free next working day delivery on all charging cables.
Next working day delivery applies if ordered by 2pm Mon-Fri.
Weekend & bank holiday Friday orders will be delivered the next working Tuesday.
Bank Holiday Monday orders will be delivered the next working Wednesday.


Product information

Mode-2 EV charger (3 pin UK plug to Type 2 EV plug), 5 metre total length.
Charges at 10A, 2.3kW (up-to 8 miles per charging hour).  IP65 weatherproof (when connected to vehicle, otherwise IP55).

Code : EVCM22135-01

  • Provides safe and intelligent portable EV charging for all plug-in electric vehicles*
  • Perfect for travelling to destinations that only offer a domestic (13A UK 3 pin) socket
  • UK 3 pin plug to Type 2 EV plug
  • Charges up-to 10A, 2.4kW - up-to 8 miles per charging hour
  • 5 metres of high performance cable
  • IP65 rated (Control box) - IP65 when connected to vehicle, IP55 when not in use and end-cap applied
  • LED charging status indicator
  • Optional carry case available (Code : EVCASE)

*Any portable charger used for regular charging should be connected via a dedicated circuit including a socket designed and marked "Suitable for EV charging"

  • 5 metre total length
CODE : EVCM22135-01
CABLE LENGTH : 5 METRE TOTAL LENGTH
EV MODE : 2
PLUG TYPE (TO POWER SOCKET) 3-PIN 13A DOMESTIC UK PLUG
PLUG TYPE (TO VEHICLE SOCKET) TYPE 2 (IEC62196)
STANDARDS BS EN 62752, BS EN 61851-1
INPUT 220-250V AC 50/60Hz 13A
CHARGING OUTPUT 220-250V AC 50/60Hz 10A
IP RATING IP65 WHEN CONNECTED TO VEHICLE. IP55 WHEN NOT IN USE AND END CAP APPLIED
CABLE COLOUR BLACK
PLUG COLOUR BLACK/BLUE
RATED CURRENT 10A MAX (as per safety regulations define in Mode 2)
RATED VOLTAGE 230V ~ 50HZ
OPERATING TEMPERATURE -25° TO +50°C
CABLE SPECIFICATION H07BZ5-F 3x1.5mm²+1x0.5mm², H05RR-F 3G 1.5mm²
WEIGHT 1.9KG
UV STABILITY UV STABLE
WARRANTY 3 YEARS
ACCESSORIES EV CABLE CARRY CASE (CODE : EVCASE-01) ORDER SEPARATELY
NOTES Any portable charger used for regular charging should be connected via a dedicated circuit including a socket designed and marked "Suitable for EV charging"
