CODES :

EVWC2S22GGR (22KW / WI-FI / LAN / 4G / RFID)

TYPE :

SOCKETED

SOCKET / PLUG :

TYPE 2 SOCKET WITH AUTO LOCK

KW :

UP TO 22KW AC 32A MODE 3

MIN CHARGE CURRENT :

CONFIGURABLE, 6 - 32A

ELECTRICAL INPUT :

THREE PHASE 400-415V, 50-60Hz

COLOUR :

BASE & BODY RAL 9005 (BLACK)

TRIM - RAL 7016 (ANTHRACITE GREY)

OPTIONAL COLOURED TRIMS AVAILABLE AS ACCESSORIES

CABLE MANAGEMENT :

BUILT IN CABLE WRAP

PEN PROTECTION :

YES, IN-BUILT EARTH DISCONNECTION

EARTH ROD :

NOT REQUIRED

RCD PROTECTION :

YES, 6mA DC, 30mA AC TYPE-A, IN-BUILT

OVERLOAD AND FAULT PROTECTION :

OVER CURRENT AND FAULT PROTECTION

ELECTRICAL CLASS :

CLASS 1, HOUSING CLASS 2

LOAD BALANCING :

REQUIRES 3x EVA120CT1 LOAD MANAGEMENT KITS (NOT SUPPLIED. ORDER SEPARATELY)

METER ACCURACY :

2% CLASS C EQUIVALENT INTERNAL METER WITH OPTION FOR CONNECTION TO EXTERNAL RS485 MODBUS METER

CONSUMER UNIT REQUIREMENTS :

40A MCB OR 30mA TYPE-A RCD (DEPENDENT ON CABLE TYPE &/OR ROUTE)

TERMINALS :

COMBI SCREW FIRST FIX PLUG CONNECTOR

INDICATOR :

RGB LED AND BUZZER

INDICATOR MODES :

BLUE - STANDBY, FLASHING BLUE - PREPARING, GREEN - CHARGING, YELLOW - NO NETWORK, RED - ERROR

HOUSING :

UV STABILISED POLYCARBONATE

WALL FIXING :

4 POINT WITH HORIZONTAL AND VERTICAL ADJUSTMENT, SUPPLIED FIXING HOLE TEMPLATE. FIXING HOLE CENTRES :110 HORIZONTAL, 145 VERTICAL (MM)

IP / IK RATING :

IP55 / IK10

SOC MODULE :

AI ESP32-S SOC

WI-FI & ETHERNET :

2.4Ghz 802.11 B/G/N & RJ45

WI-FI SECURITY :

WPA/WPA2/WPA2-ENTERPRISE/WPS

BLUETOOTH :

4.2 BR/EDR and BLE

CONNECTION PROTOCOL :

OCPP 1.6J

4G DATA :

3 YEARS INCLUDED, WHEN USED WITH MONTA (ON THE INCLUDED PACKAGE). TOP-UP ONLINE TO CONTINUE SERVICE AFTER 3 YEAR

APP :

POWERED BY MONTA

OPERATING TEMP :

-25 TO +40°C

SOFTWARE & FIRMWARE UPDATE :

OVER-THE-AIR

WARRANTY :

3 YEARS

STANDARDS & APPROVALS :

IEC61851-1, IEC61439-7, IEC 62955, IC 61851-21-2, BS EN62196, EN301 511, EN 301 908-1/2/13, EN 301 489-3, EN 300 330, EMC COMPLIANT, CE, UKCA, THE ELECTRIC VEHICLES (SMART CHARGE POINTS) REGULATIONS 2021 INCLUDING SCHEDULE 1

SUPPLIED ACCESSORIES :

5x BASE FIXING WASHERS,5x ASSEMBLY LID BOLTS, 1x BLANKING PLUG AND 1x 25MM COMPRESSION GLAND, USER-SIDE CONNECTOR, CORD GRIP AND 2x CORD GRIP ASSEMBLY SCREWS

DIMENSIONS (MM) :

305 (H) x 201 (W) x 115 (D)

ADDITIONAL :

ANTI TAMPER DETECTION - 2 LAYER PROTECTION, BLUETOOTH TO BLUETOOTH COMMISSIONING

ACCESSORIES :

SINGLE CHARGER STAND(EVASTAND12S)

TWIN CHARGER STAND(EVASTAND12T)

COMPATIBLE WITH EV-TOWER STANDS WITH BG SYNCEV MOUNTING PLATE (WWW.EV-TOWER.CO.UK)

LOAD MANAGEMENT KIT(EVA120CT1)

CHARGING CABLES

COLOURED FASCIAS(VARIOUS OPTIONS, SEE SYNCEV.CO.UK)
